Multi

Extractor is applicable to the project operations of water decoating under normal and compressed pressure, temperature d;

Send inquiry

Basic Info.

Model NO.	LNT-4T
Customized	Customized
Condition	New
Warranty	1 Year
Volume	10L-20t (Customized)
Material	SS304 or SS316L
Transport Package	Plywood Case
Specification	20-5000L
Trademark	LENO
Origin	China
Production Capacity	100 Set/Month

Product Description

Multi-Functional Stainless Steel Herb Extracting Tank Extractor Tank

Sanitary stainless steel concentrator extractor tank extraction machine for pharmacy essential perfume oil herb tea ethanol
Profile type	Extractor
material	SS304 or SS316L
Volume	10L-20T (Customized)
Pressure	Vacuum-1Mpa
Structure	inner layer+jacket+insulation
heating mode	electric/steam heating
Agitator type	customized
PARTS DETAILS	1.Quick open manhole / Pressure manhole
	2.Various types of CIP cleaners
	3.Sterile respirator
	4.Adjustable Legs
	5.Inlet and Outlet sanitary valve.
	6.Thermometer (According to customer requirements ).
	7.Paddle blender .(According to customer requirements).
	8.Liquid level meter and lever controller (According to customer requirements) .
	9.Platform

Multi-Functional Stainless Steel Herb Extracting Tank Extractor Tank

Extractor is applicable to the project operations of water decoating under normal and compressed pressure, temperature dipping, thermal refluxing, forced circulation, diacolation, extraction of aroma oil and reclamation of organic solvent,etc, which are in such industries as Chinese traditional medicine, plants, food and chemistry.

Specifications	Volume (L)	Design pressure tank(Mpa)	Design pressure jacket(Mpa)	Diameter of residue discharging door(mm)	heating area (m2)	condensing area (m2)	cooling area (m2)	Filtering area (m2)
LNT-1T	1200L	0.09	0.3	600mm	3	6	1	3
LNT-2T	2300L	0.09	0.3	800mm	4.7	10	1	3
LNT-3T	3200L	0.09	0.3	1000mm	6	12	1.5	3
LNT-6T	6300L	0.09	0.3	1200mm	7.5	15	2	5
LNT-8T	8500L	0.09	0.3	1200mm	9.5	18	2	5
LNT-10T	11000L	0.09	0.3	1200mm	12	20	2	6
We can customize the equipment according to customer requirements.

Q1	Are you trade or manufacturer?
A	We are a factory with an international sales company specialized in support for global distributors.
Q2	Can you provide instant technical consulting services?
A	We are able to discuss technical details and offer suggestions over the phone in English. You can get the answers in minutes, instead of days.
Q3	What's the difference between Ready-To-Ship and Customized products?
A	Some of RTS standard products are in stock and ready to ship in 2-3 days. We can also quick design and make the drawings for customer requirements, then begin the production.
Q4	What is the payment terms?
A	We accept Alibaba Trade Assurance Order, also can T/T and L/C.
Q5	How to choose the shipment way?
A	It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers)
Q6	How about the after-sales service?
A	Fast after-sales support. Our products have a one-year warranty and free permanent consulting services.
